Identifying Front Door Glass Options on the NV200
Determining the correct replacement front door glass on this van comes down to tracking the production build date rather than sorting through complex factory option lists. Nissan kept the glass specification straightforward across the cargo S, SV, and dedicated Taxi packages: every front door uses single-pane tempered safety glass with a light-green solar-absorbing tint. You will not find embedded defroster grids, rain sensors, acoustic interlayers, or integrated antennas on either front side window.
The distinction lies strictly in Nissan's mid-cycle hardware revision. Vehicles manufactured up to roughly February 2015 were fitted with original part numbers 80301-3LM0A (left) and 80300-3LM0A (right). Later builds shifted to updated part numbers 80301-4AJ0A and 80300-4AJ0A. In the aftermarket glass catalog, both date ranges consolidate cleanly under standard National Auto Glass Specifications (NAGS) numbers, ensuring the glass contour and dual mounting brackets seat correctly into the carrier.
| Position | NAGS Number | Nissan Early OEM (2013–02/2015) | Nissan Late OEM (2015–2021) |
|---|---|---|---|
| Front Left (Driver Side) | FD25930 | 80301-3LM0A | 80301-4AJ0A |
| Front Right (Passenger Side) | FD25929 | 80300-3LM0A | 80300-4AJ0A |
Mechanical Linkages and Common Track Binding
The front window rides inside a rigid, fully framed steel door shell rather than a frameless design. It relies on a flexible rubber glass run channel (part 80330-3LM0A) that travels down into the door cavity behind the side-view mirror base mount and corner triangle trim. The lower edge of the glass features two bonded mounting clips that secure directly to a cable-and-pulley window regulator assembly (Nissan reference 80720-JX00B on the right side).
Because these vehicles see heavy daily commercial service, road grime, salt, and dust regularly accumulate in the vertical rubber run channels. When these seals dry out or pack with dirt, friction spikes. The driver-side one-touch auto-down system will either hesitate, chatter against the outer waistline belt seal, or stall the motor entirely. I cover every replacement pane with a one-year glass defect warranty alongside a lifetime guarantee on my installation workmanship, which protects you if unexpected mechanical stress reveals an issue with fitment.
Left unaddressed, excessive drag inside the tracks often stretches the regulator cables or breaks the plastic spool inside the motor drive. If your window tilts forward while rolling up or sits cocked inside the upper door frame, the glass clips have likely separated or the regulator cable has frayed off its pulley track.
Cargo Area Glass Versus Front Door Panes
If your cargo van came from the factory with side glass behind the cab, it is crucial not to confuse those stationary or sliding door panels with the cab glass. While the front roll-up windows use standard green-tint FD25930 and FD25929 tempered units, rear sliding cargo door glass (such as factory right-hand panel 90300-3LM2D) utilizes completely different structural dimensions, privacy tints, and mounting setups tailored specifically to the cargo body stamping.
Before replacing broken front glass, check the flexible rubber boot running between the door frame and the A-pillar. Repeated door swings on high-mileage delivery routes can fatigue the copper wiring inside that harness, mimicking a bad regulator motor or switch when the glass stops moving.
